P0412 Code: Secondary Air Injection System Switching Valve “A” Circuit

The secondary air injection (SAI) system forces fresh air into the exhaust system to help in the oxidizing process happening in the exhaust manifold or catalytic converter. It reduces HC and CO emissions by providing fresh air into the exhaust system.

A typical SAI system has a check valve that protects other components from reverse exhaust flow, as well as various air management valves. Once the powertrain control module (PCM) detects an issue with the SAI system, it will log a P0412 code.

What Does the P0412 Code Mean?

Diagnostic trouble code (DTC) P0412 stands for “Secondary Air Injection System Switching Valve ‘A’ Circuit.”

The SAI system operates during cold engine startup, pumping fresh air into the exhaust and combining it with the post-combustion HC and CO to provide secondary oxidation. This process converts the residual HC and CO to water vapor and CO2. A switching valve is used to allow air to flow from the SAI pump to the exhaust stream.

Problems can arise with the switching valve and related components. Once this happens, on-board diagnostics will log a P0412 code.

Note: The definition of code P0412 might be different depending on the vehicle manufacturer. Consult the appropriate repair manual or repair database for the exact code definition.

What are the Common Causes of the P0412 Code?

• Wiring issues
• Damaged secondary air pump switching valve
• Clogged or disconnected vacuum hose
• PCM failure

What are the Common Symptoms of the P0412 Code?

• Illuminated check engine light
• Increased tailpipe emissions
• Engine running rich

How to Diagnose the P0412 Code

DTC P0412 is a generic powertrain code that vehicles equipped with an OBD-II system can log. But despite being a common trouble code, its steps for diagnosis and repair can vary from one vehicle to another.

If you’re not familiar with the process of diagnosing trouble codes, it’s a good idea to bring your vehicle to the nearest auto repair shop and have a trained professional do the job for you. Otherwise, you can go ahead and do it yourself.

To help you out, we’ve gathered a couple of videos to give you an idea about what the process might involve.

How to Fix the P0412 Code

There’s not a single solution to fix every trouble code in the book. The steps for fixing DTC P0412 can differ, depending on your vehicle’s year, make, and model.

If you’re not confident with your DIY skills yet, you can always have a certified mechanic do the job for you to ensure that the right steps are followed. But if you think you have the skills and technical knowledge to do it, then you can go ahead and fix the problem on your own.

Before you start, make sure you have the right tools and repair guides. Manuals like those from Chilton or an ALLDATA subscription contain vehicle-specific repair information, so you might want to check those out before proceeding.
